Part No. 56-189.WO (oro2u.com)

WOSSNER CONNECTING ROD KIT, CONROD

HONDA 1999-08 TRX400EX

CONNECTING ROD SIZE PLEASE SEE DRAWING SIZE mm. A = 122.6, B = 20, C = 34, D = 21, E = 19, F = 66

CRANK PIN:34 X 66 MM, WITHOUT WASHER

BOTTOM BEARING. 34 X 43 X 20MM

Wossners forged high performance connecting rods provide the highest quality for maximum performance and reliability.

The connecting rods are made of the best material which is CNC machined to remove all surface imperfections. The rods

are then machined to final size and has then been shot- peened to achieve the ultimate in strength and durability. Made in Germany.
