PISTON KIT 04-07 KTM300 72.00, WOSSNER 8219DB FORGED
This Wossner 8219DB piston kit features a 72.01mm bore, offering a +0.01mm oversize from standard, and is engineered for KTM 300cc two-stroke engines from 2004 to 2007. The forged construction ensures enhanced durability and optimal thermal performance for off-road applications.
Features
-
+0.01mm oversize forged piston for improved fit in slightly worn cylinders
-
Engineered for efficient heat transfer from the combustion chamber to cylinder walls
-
Elliptical design for uniform bearing surface under thermal expansion
-
Prevents localised pressure points and piston collapse
-
Manufactured in Germany
Specifications
-
Bore diameter: 72.01 mm
-
Display displacement: 293 cm³
-
Stroke: 72.00 mm
-
Clearance: 0.06 mm
-
Compression ratio: 2-stroke (Wossner and OEM specification)
-
Compression height: 38.00 mm
Cross-Reference OEM Part Numbers
-
Not provided for this variant
Included Components
-
Piston kit part number: 56-W858.B.WO
-
Rings (2x): RSB7200
-
Circlip: CW18
-
Wrist pin: WP033
-
Gasket: D2024-EST
-
Connecting rod: P2023
Vehicle Fitments
-
KTM EXC 300 2004–2007
-
KTM MXC 300 2004–2007
-
KTM XC 300 2004–2007
-
KTM XC-W 300 2004–2007
