The Wossner 8098DA piston kit is a standard-size forged piston specifically designed for Suzuki RM125 models from 2004 to 2012. With a 54.00mm bore and a 53.95mm piston diameter, this piston delivers high strength and consistent thermal performance for two-stroke engines. Its elliptical shape enables even expansion and load distribution, minimising wear and preventing piston collapse. Precision-manufactured in Germany, this component ensures long-lasting reliability and performance under demanding conditions.

Features

•


  Forged piston construction for superior durability and strength





•


  Engineered for efficient heat transfer from combustion chamber to cylinder walls





•


  Elliptical design distributes thrust loads evenly to reduce localised stress





•


  Manufactured in Germany with high-precision standards




Specifications

•


  Bore: 54.00 mm





•


  Piston Diameter: 53.95 mm





•


  Display Displacement: 125 cm³





•


  Stroke: 54.50 mm





•


  Piston Clearance: 0.05 mm





•


  Compression Height: 29.50 mm





•


  Compression Ratio (Wossner and OEM): 2-stroke





•


  Lock Part Number: CW15





•


  Pin Part Number: WP032





•


  Ring Set Part Number: RSB5400





•


  Rod Part Number: P2016




Cross-Reference OEM Part Numbers

•


  12110-36E31-0F0





•


  09104823





•


  835M05400





•


  12101-36821





•


  12110-36F00-0F0





•


  12141-36F00





•


  12151-01B41





•


  09381-15001




Vehicle Fitments

•


  Suzuki RM125 2004 - 2012
