Wossner forged piston kit 8880DB is a +0.01mm oversized piston with a 96.01mm nominal bore (measured at 95.97mm), specifically designed for Honda CRF450R models from 2013 to 2014. Manufactured in Germany, this high-performance piston ensures superior strength, optimal heat transfer, and reliable engine fitment under demanding conditions.

Features

•


  Forged piston construction for maximum strength and reliability





•


  Elliptical design distributes loads uniformly during thermal expansion





•


  Engineered for effective combustion heat transfer to the cylinder wall





•


  Reduces localised pressure to prevent piston collapse





•


  Made in Germany




Specifications

•


  Bore: 96.01mm (Measured: 95.97mm)





•


  Display Volume: 449 cm³





•


  Stroke: 62.10mm





•


  Clearance: 0.04mm





•


  Compression Height: 20.70mm





•


  Wossner Compression Ratio: OEM





•


  OEM Compression Ratio: 12.50:1





•


  Dome Volume: -2.60 cm³





•


  Part No.: 56-W916.B.WO (Wossner 8880DB)





•


  Ring Set: 960ADS-2





•


  Lock P/N: CW19





•


  Pin P/N: WP028




Vehicle Fitments

•


  2013 Honda CRF450R





•


  2014 Honda CRF450R
