PISTON KIT 1987 LT250 67.00, WOSSNER 8258DA SUZUKI ATV
Wossner Forged Piston Kit 67.00mm Bore ā Suzuki LT250 1987 (8258DA STD)
This Wossner forged piston kit with a standard bore size of 67.00mm (actual 66.94mm) is designed for the 1987 Suzuki LT250 ATV. It delivers high-performance reliability, thermal efficiency, and superior structural integrity through its forged construction. The elliptical piston profile promotes even thrust load distribution, reducing the chance of localised stress and collapse during thermal expansion. Manufactured in Germany for precision and performance.
Features
-
Forged piston for increased durability and strength
-
Optimised for efficient combustion heat transfer to cylinder walls
-
Elliptically shaped for even bearing surface under heat expansion
-
Designed for 2-stroke engine configuration
-
Made in Germany
Specifications
-
Bore Size: 67.00mm (Standard)
-
Actual Bore: 66.94mm
-
Compression Height: 37.20mm
-
Clearance: 0.06mm
-
Stroke: 70.00mm
-
Displacement: 246 cmĀ³
-
Wossner Compression Ratio: 2-stroke
-
OEM Compression Ratio: 2-stroke
Cross-Reference OEM Part Numbers
-
Wossner Piston: 8258DA
-
Ring Set: RSB6700 (x2)
-
Lock: CW18
-
Pin: WP033
-
Internal Reference: 56-W577+0.00.WO
Vehicle Fitments
-
1987 Suzuki LT250
Product Information
Product Information
Shipping & Returns
Shipping & Returns
PISTON KIT 1987 LT250 67.00, WOSSNER 8258DA SUZUKI ATV
PISTON KIT 1987 LT250 67.00, WOSSNER 8258DA SUZUKI ATV
Wossner Forged Piston Kit 67.00mm Bore ā Suzuki LT250 1987 (8258DA STD)
This Wossner forged piston kit with a standard bore size of 67.00mm (actual 66.94mm) is designed for the 1987 Suzuki LT250 ATV. It delivers high-performance reliability, thermal efficiency, and superior structural integrity through its forged construction. The elliptical piston profile promotes even thrust load distribution, reducing the chance of localised stress and collapse during thermal expansion. Manufactured in Germany for precision and performance.
Features
-
Forged piston for increased durability and strength
-
Optimised for efficient combustion heat transfer to cylinder walls
-
Elliptically shaped for even bearing surface under heat expansion
-
Designed for 2-stroke engine configuration
-
Made in Germany
Specifications
-
Bore Size: 67.00mm (Standard)
-
Actual Bore: 66.94mm
-
Compression Height: 37.20mm
-
Clearance: 0.06mm
-
Stroke: 70.00mm
-
Displacement: 246 cmĀ³
-
Wossner Compression Ratio: 2-stroke
-
OEM Compression Ratio: 2-stroke
Cross-Reference OEM Part Numbers
-
Wossner Piston: 8258DA
-
Ring Set: RSB6700 (x2)
-
Lock: CW18
-
Pin: WP033
-
Internal Reference: 56-W577+0.00.WO
Vehicle Fitments
-
1987 Suzuki LT250
Original: $266.73
-65%$266.73
$93.36Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Wossner Forged Piston Kit 67.00mm Bore ā Suzuki LT250 1987 (8258DA STD)
This Wossner forged piston kit with a standard bore size of 67.00mm (actual 66.94mm) is designed for the 1987 Suzuki LT250 ATV. It delivers high-performance reliability, thermal efficiency, and superior structural integrity through its forged construction. The elliptical piston profile promotes even thrust load distribution, reducing the chance of localised stress and collapse during thermal expansion. Manufactured in Germany for precision and performance.
Features
-
Forged piston for increased durability and strength
-
Optimised for efficient combustion heat transfer to cylinder walls
-
Elliptically shaped for even bearing surface under heat expansion
-
Designed for 2-stroke engine configuration
-
Made in Germany
Specifications
-
Bore Size: 67.00mm (Standard)
-
Actual Bore: 66.94mm
-
Compression Height: 37.20mm
-
Clearance: 0.06mm
-
Stroke: 70.00mm
-
Displacement: 246 cmĀ³
-
Wossner Compression Ratio: 2-stroke
-
OEM Compression Ratio: 2-stroke
Cross-Reference OEM Part Numbers
-
Wossner Piston: 8258DA
-
Ring Set: RSB6700 (x2)
-
Lock: CW18
-
Pin: WP033
-
Internal Reference: 56-W577+0.00.WO
Vehicle Fitments
-
1987 Suzuki LT250
