PISTON KIT 1987 RM125 56.00, WOSSNER 8122D200 SUZUKI MX
This Wossner 56.00mm (+2.00 oversize) forged piston kit is designed for the Suzuki RM125 1987 model. Built for two-stroke performance, the piston features a forged body and elliptical design that enhances heat transfer efficiency and provides uniform load distribution. Manufactured in Germany, it ensures reliability under thermal and mechanical stress during high-performance operation.
Features
-
Forged piston for high strength and durability
-
Elliptical design maintains consistent bearing surface during heat expansion
-
Thrust load is evenly distributed to reduce localised stress and prevent piston collapse
-
Engineered for efficient combustion heat transfer to the cylinder walls
-
Manufactured in Germany
Specifications
-
Bore: 56.00mm
-
Actual diameter: 55.94mm
-
Displacement: 123 cm³
-
Stroke: 70.00mm
-
Clearance: 0.06mm
-
Compression height: 37.00mm
-
Compression ratio: 2-stroke
Cross-Reference OEM Part Numbers
-
Piston Kit Part No.: 56-W557+200.WO
-
Wossner Piston Kit No.: 8122D200
-
Lock: CW14
-
Pin: WP025
-
Ring Set: RSB5600 x 2
Vehicle Fitments
-
Suzuki RM125 1987
