PISTON KIT 1988 RM125 54.50, WOSSNER 8138D050 SUZUKI MX 12110-14513
The Wossner 8138D050 piston kit is designed for the 1988 Suzuki RM125, featuring a 54.50 mm bore for +0.50 mm oversize applications. Precision-manufactured in Germany, this forged piston offers superior strength and efficient thermal transfer. Its elliptical design promotes even bearing surface contact under high-temperature expansion, minimising localised pressure and reducing the risk of piston collapse. This kit includes all necessary components for dependable engine rebuilding.
Features
-
Forged piston delivers high strength and thermal efficiency
-
Enhanced heat transfer from combustion chamber to cylinder walls
-
Elliptical profile ensures uniform pressure distribution under heat
-
Reduces the likelihood of piston collapse due to thermal stress
-
Made in Germany for precision and performance
Specifications
-
Bore Size: 54.50 mm
-
Actual Bore Diameter: 54.44 mm
-
Stroke: 54.00 mm
-
Display Displacement: 123 cm³
-
Clearance: 0.06 mm
-
Compression Ratio (Wossner and OEM): 2-stroke
-
Compression Height: 29.50 mm
Cross-Reference OEM Part Numbers
-
12110-14513
Cross-Reference Wossner Part Numbers
-
Piston Kit: 8138D050
-
Lock: CW15
-
Pin: WP032
-
Ring Set: RSB5450
-
Rod: P2015
-
Part No.: 56-W568+050.WO
Vehicle Fitments
-
Suzuki RM125 (1988)
