PISTON KIT 1988 RM125 56.00, WOSSNER 8138D200 SUZUKI MX
The Wossner 8138D200 piston kit is engineered for the 1988 Suzuki RM125 and features a 56.00 mm bore for +2.00 mm oversize applications. Made in Germany with forged construction, this piston provides excellent durability and efficient heat transfer. Its elliptical design ensures a consistent bearing surface during thermal expansion, effectively distributing thrust loads and reducing the risk of piston collapse. This kit includes all essential components for reliable engine rebuilds.
Features
-
Forged piston offers enhanced strength and durability
-
Optimised for heat dissipation from the combustion chamber
-
Elliptical design ensures even load distribution during expansion
-
Helps prevent piston failure under thermal stress
-
Manufactured in Germany for high precision and quality
Specifications
-
Bore Size: 56.00 mm
-
Actual Bore Diameter: 55.94 mm
-
Stroke: 54.00 mm
-
Display Displacement: 123 cm³
-
Clearance: 0.06 mm
-
Compression Ratio (Wossner and OEM): 2-stroke
-
Compression Height: 29.50 mm
Cross-Reference Wossner Part Numbers
-
Piston Kit: 8138D200
-
Lock: CW15
-
Pin: WP032
-
Ring Set: RSB5600
-
Rod: P2015
-
Part No.: 56-W568+200.WO
Vehicle Fitments
-
Suzuki RM125 (1988)
