PISTON KIT 86-88 YZ125 56.75, WOSSNER 8118D075 YAMAHA MX
This Wossner 56.75mm (+0.75 oversize) forged piston kit is designed for Yamaha YZ125 models from 1986 to 1988. Featuring a forged build and elliptical design, the piston is engineered for thermal expansion control, even thrust load distribution, and reliable performance in two-stroke engines. Manufactured in Germany, it ensures efficient heat transfer from the combustion chamber to the cylinder walls under demanding conditions.
Features
-
Forged piston construction for enhanced strength and durability
-
Elliptical design provides consistent bearing surface under thermal expansion
-
Even distribution of thrust loads minimises localised stress and prevents piston collapse
-
Optimised for efficient heat transfer from combustion chamber to cylinder walls
-
Manufactured in Germany
Specifications
-
Bore: 56.75mm
-
Actual diameter: 56.69mm
-
Displacement: 123 cm³
-
Stroke: 50.00mm
-
Clearance: 0.06mm
-
Compression height: 30.00mm
-
Compression ratio: 2-stroke
Cross-Reference OEM Part Numbers
-
Piston Kit Part No.: 56-W559+075.WO
-
Wossner Piston Kit No.: 8118D075
-
Lock: CW16
-
Pin: WP036
-
Ring Set: RSB5675
Vehicle Fitments
-
Yamaha YZ125 1986
-
Yamaha YZ125 1987
-
Yamaha YZ125 1988
