Wossner forged piston kit engineered for Suzuki RM125 models from 1989 to 1999, featuring a 55.50mm bore for significant oversize repairs. This piston offers outstanding strength, superior heat transfer capabilities, and uniform load distribution. Its elliptical design minimises localised stresses under high-temperature conditions, reducing the risk of piston collapse. Manufactured in Germany with precision craftsmanship.

Features

•


  Forged construction ensuring high strength and durability





•


  Optimized design for effective combustion chamber heat transfer





•


  Elliptical geometry promoting uniform pressure distribution





•


  Manufactured in Germany




Specifications

•


  Bore Size: 55.50mm





•


  Actual Piston Size: 55.45mm





•


  Display Capacity: 123 cm³





•


  Stroke: 54.00mm





•


  Clearance: 0.05mm





•


  Compression Ratio (Wossner): 2-stroke





•


  Compression Ratio (OEM): 2-stroke





•


  Compression Height: 29.50mm




Cross-Reference OEM Part Numbers

•


  Piston Kit: 8055D150





•


  Lock: CW15





•


  Pin: WP032





•


  Ring Set: RSB5550





•


  Additional Part Number: 56-W641.C.WO




Vehicle Fitments

•


  1989 Suzuki RM 125





•


  1990 Suzuki RM 125





•


  1991 Suzuki RM 125





•


  1992 Suzuki RM 125





•


  1993 Suzuki RM 125





•


  1994 Suzuki RM 125





•


  1995 Suzuki RM 125





•


  1996 Suzuki RM 125





•


  1997 Suzuki RM 125





•


  1998 Suzuki RM 125





•


  1999 Suzuki RM 125
