Wossner Forged Piston Kit 68.50mm Bore – Yamaha DT200R / WR200

This Wossner forged piston kit is designed for Yamaha DT200R (1988–1991) and WR200 (1992–1998) models, with a bore size of 68.50 mm and a piston diameter of 68.44 mm (+2.50 mm oversize). Built for 2-stroke engine performance, the piston ensures superior heat transfer, strength, and dimensional stability. Its elliptical design distributes loads evenly, reducing stress under thermal expansion. Precision-manufactured in Germany.

Features

•


  Forged piston construction for enhanced strength and reliability





•


  Optimised combustion heat dissipation to cylinder walls





•


  Elliptical profile for consistent bearing surface and minimised pressure points





•


  Made in Germany for high manufacturing accuracy




Specifications

•


  Bore Size: 68.50 mm





•


  Piston Diameter: 68.44 mm





•


  Engine Displacement: 195 cm³





•


  Stroke: 57.00 mm





•


  Clearance: 0.06 mm





•


  Compression Height: 29.90 mm





•


  Compression Ratio: 2-stroke (Wossner and OEM)




Cross-Reference Wossner Part Numbers

•


  Piston Kit: 8070D250





•


  Lock: CW16





•


  Pin: WP027





•


  Ring Set: RSB6850 x 2




Vehicle Fitments

•


  Yamaha DT200R (1988–1991)





•


  Yamaha WR200 (1992–1998)
