Wossner Piston Kit 8188D050 is a high-quality forged piston specifically designed for Yamaha YZ80 motorcycles from 1993 to 2001, featuring a 47.50mm bore (+0.50 US Bore). Manufactured in Germany, this piston ensures optimal heat transfer and strength, while its elliptical design evenly distributes thrust forces, minimising stress and the risk of piston failure.

Features

•


  Forged piston for enhanced mechanical strength and longevity





•


  Elliptical shape provides uniform load distribution under heat expansion





•


  Efficient combustion heat transfer to cylinder walls





•


  German-made for high manufacturing precision




Specifications

•


  Bore: 47.50 mm





•


  Actual Piston Diameter: 47.45 mm





•


  Stroke: 47.80 mm





•


  Displacement: 82 cm³





•


  Clearance: 0.05 mm





•


  Compression Height: 26.00 mm





•


  Wossner Compression Ratio: 2-stroke





•


  OEM Compression Ratio: 2-stroke




Cross-Reference OEM Part Numbers

•


  Wossner Piston: 8188D050





•


  Lock: CW14





•


  Pin: WP058





•


  Ring Set: RSB4750





•


  Rod: P2008





•


  Internal Part No: 56-W646+00050.WO




Vehicle Fitments

•


  1993 Yamaha YZ80





•


  1994 Yamaha YZ80





•


  1995 Yamaha YZ80





•


  1996 Yamaha YZ80





•


  1997 Yamaha YZ80





•


  1998 Yamaha YZ80





•


  1999 Yamaha YZ80





•


  2000 Yamaha YZ80





•


  2001 Yamaha YZ80
